De Leslie Encyclopedie



LESLIE MODEL 222 RV



Ook de 222 RV is gelijk aan de standaard 222, echter nu is de Hammond-Reverb-Kit
al standaard af-fabriek ingebouwd in de box. De box is bedoeld voor Hammond orgels zonder ingebouwde nagalm zoals de B 3, C 3 en RT 3.

  • Height 30 inches.
  • Width 40 inches.
  • Depth 20 inches.
  • Has 2 rotors and 2 speakers.
  • Accepts 1 channel from the source.
  • The amp provides 40 Watts of RMS power.
  • A 6 pin connector:
    1. G/G Signal Black
    2. Audio Ground
    3. AC Power Return
    4. AC Power Hot
    5. No Connection/Preamp B+
    6. G/G Signal Red
  • Leslie recommends it for use with Hammond only.
  • Has a warm-toned vacuum tube amp.
  • Has a reverb system inside.
  • Has a decorator styled cabinet.
