De Leslie Encyclopedie





LESLIE MODEL 122XB ULTIMO



Dit model Leslie werd speciaal ontworpen om aan te sluiten bij de nieuwe vormgeving die opgang deed in de Hammond B3-ULTIMO, waarvan hieronder een afbeelding:

Leslie 122XB ULTIMO in hoogglans zwart



  • Height 41.625 inches.
  • Width 29.25 inches.
  • Depth 20.625 inches.
  • Has 2 rotors and 2 speakers.
  • Accepts 1 channel from the source.
  • The amp provides 40 Watts of RMS power.
  • An 11 pin connector:
    1. Audio Signal Hot
    2. No Connection
    3. No Connection
    4. Audio Ground
    5. Control Supply Common
    6. Control Circuit Common
    7. Fast Motor Control
    8. Slow Motor Control
    9. No Connection
    10. No Connection
    11. 29 VDC for control head
  • Leslie recommends for use with Hammond Ultimo series.
  • Has a warm-toned vacuum tube amp.
  • Has a black polished cabinet
